Gateway UG65 MS with cellular, indoor US Version LoRaWAN
US915 indoor LoRaWAN gateway with integrated 4G LTE cellular backhaul.
The Milesight UG65 North America version provides 8-channel LoRaWAN connectivity with Ethernet, Wi-Fi and LTE Cat 1. It supports around 2,000 devices and includes an embedded network server for IoT and building integration.
- US915 LoRaWAN version
- 4G LTE Cat 1 cellular
- 8 LoRaWAN channels
- Ethernet, Wi-Fi and PoE
- Supports around 2,000 devices
US915 indoor LoRaWAN gateway with cellular backhaul
The Gateway UG65 MS with cellular, indoor US Version LoRaWAN is a high-performance 8-channel LoRaWAN gateway for indoor IoT installations in North America. It supports the US915 frequency plan and combines LoRaWAN connectivity with Ethernet, Wi-Fi and 4G LTE cellular backhaul.
The gateway is based on the Semtech SX1302 LoRa chip and a quad-core 64-bit processor. It supports around 2,000 LoRaWAN Class A, B and C devices, making it suitable for smart buildings, energy monitoring and larger wireless sensor networks.
US915 LoRaWAN and cellular connectivity
The North America version supports US915 and includes 4G LTE Cat 1 connectivity on bands B2, B4, B5, B12, B13 and B66. Ethernet and Wi-Fi can be used alongside cellular connectivity for flexible backhaul and WAN failover.
The embedded network server supports MQTT, HTTP, BACnet/IP, BACnet/SC and Modbus integration, allowing LoRaWAN sensor data to be connected to IoT platforms, BMS and PLC systems.
See the official Milesight UG65 product information and North America documentation for detailed configuration and specifications.
Product benefits
- US915 LoRaWAN version for North America
- 8-channel LoRaWAN gateway
- 4G LTE Cat 1 cellular backhaul
- Ethernet and 2.4 GHz Wi-Fi connectivity
- Supports around 2,000 LoRaWAN devices
- Built-in LoRaWAN network server
- MQTT, HTTP, BACnet and Modbus integration
- PoE, DC and USB-C power options
Technical specifications
| Product | Gateway UG65 MS with cellular, indoor US Version LoRaWAN |
|---|---|
| Manufacturer | Milesight |
| LoRaWAN frequency | US915 |
| LoRa chipset | Semtech SX1302 |
| LoRaWAN channels | 8 half/full-duplex channels |
| Supported devices | Approximately 2,000 Class A/B/C devices |
| Cellular | 4G LTE Cat 1 |
| Cellular bands | B2 / B4 / B5 / B12 / B13 / B66 |
| SIM | 1 × mini SIM (2FF) |
| Ethernet | 1 × Gigabit RJ45 WAN with PoE support |
| Wi-Fi | 2.4 GHz IEEE 802.11 b/g/n |
| Integration | MQTT(S), HTTP(S), BACnet/IP, BACnet/SC and Modbus |
| Power supply | 9–24 V DC, IEEE 802.3af PoE or 5 V USB-C |
| Protection rating | IP65 |
| Dimensions | 180 × 110 × 55.5 mm |
| Operating temperature | -40 to +70 °C |
Applications
- Smart buildings and offices
- Energy and utility monitoring
- US915 LoRaWAN sensor networks
- BMS and PLC integration
- Installations requiring cellular backup connectivity
Installation and connection
The UG65 can be mounted on a desktop, wall or pole and powered through PoE, DC or USB-C. Configure the gateway for US915 operation and connect it through Ethernet, Wi-Fi or 4G LTE according to the installation requirements.
