Energy meter Sharky 775 10m3 200mm DN40 TempSensor Ø5,2mm LoRaWAN
Diehl SHARKY 775 ultrasonic heat meter with 10 m³/h nominal flow, DN40 size and LoRaWAN communication.
This 200 mm version uses a Ø5.2 mm temperature sensor configuration and is designed for thermal energy measurement and remote meter reading.
- Nominal flow: 10 m³/h
- DN40
- 200 mm length
- Ø5.2 mm temperature sensor
- LoRaWAN communication
Ultrasonic heat meter with integrated LoRaWAN communication
The Sharky 775 10m3 200mm DN40 TempSensor Ø5,2mm LoRaWAN is a Diehl Metering ultrasonic compact energy meter designed for heat and thermal energy measurement in building and district heating installations. This configuration has a nominal flow rate of 10 m³/h, DN40 nominal diameter and an overall installation length of 200 mm. :contentReference[oaicite:0]{index=0}
The meter uses ultrasonic flow measurement without moving mechanical measuring parts. LoRaWAN communication enables remote meter reading through a compatible LoRaWAN gateway, network server and receiving energy-management or billing platform. :contentReference[oaicite:1]{index=1}
10 m³/h DN40 thermal energy measurement
This SHARKY 775 configuration combines a qp 10 m³/h flow sensor with DN40 nominal diameter and 200 mm overall length. It is suitable for higher-flow heating and cooling circuits where compact ultrasonic energy measurement and remote data collection are required. :contentReference[oaicite:2]{index=2}
The SHARKY 775 platform supports temperature-sensor configurations including Ø5.2 mm probes, depending on the selected meter version. The meter calculates thermal energy from measured flow and the temperature difference between supply and return. :contentReference[oaicite:3]{index=3}
See the official Diehl Metering SHARKY 775 product information and documentation for detailed specifications, installation requirements and LoRaWAN documentation.
Product benefits
- Ultrasonic compact thermal energy meter
- Nominal flow rate of 10 m³/h
- DN40 nominal diameter
- 200 mm installation length
- Ø5.2 mm temperature sensor configuration
- LoRaWAN communication for remote reading
- No moving mechanical measuring parts
- Suitable for building and district energy monitoring
Technical specifications
| Product | Sharky 775 10m3 200mm DN40 TempSensor Ø5,2mm LoRaWAN |
|---|---|
| Manufacturer | Diehl Metering |
| Series | SHARKY 775 |
| Meter type | Ultrasonic compact thermal energy meter |
| Nominal flow rate qp | 10 m³/h |
| Nominal diameter | DN40 |
| Overall length | 200 mm |
| Temperature sensor diameter | Ø5.2 mm |
| Flow measurement | Ultrasonic |
| Communication | LoRaWAN |
| Application | Heat and thermal energy measurement |
Applications
- District heating metering
- Commercial building energy monitoring
- Heating and cooling plants
- Property and tenant energy metering
- Remote LoRaWAN meter reading
Installation and connection
Install the SHARKY 775 flow sensor according to the specified flow direction and the installation requirements for the selected heating or cooling circuit. Install the supply and return temperature sensors in the specified sensor positions. For remote reading, commission the LoRaWAN communication and connect the meter to a compatible LoRaWAN gateway and network server.
